Multifunctional Dual-Head Vegetable Cutter | JX-801

The JX-801 multifunctional dual-head vegetable cutter combines two vegetable processing systems in one compact machine. One side is designed for continuously cutting leafy, stem and long vegetables, while the other side processes root vegetables and firm produce into slices, strips, shreds or cubes with the appropriate cutting configuration. With an output of 600–1000 kg/h, it is suitable for central kitchens, food factories, catering suppliers and other high-volume vegetable processing operations.

Key Features

• Dual-head design processes leafy vegetables and root vegetables on one machine.

• Supports slicing, shredding, strip cutting, dicing and cut-to-length processing with suitable cutters.

• Adjustable cutting range from 1 to 60 mm for different recipes and production requirements.

• Processing capacity of approximately 600–1000 kg/h supports continuous commercial production.

• A 120 mm conveyor belt accommodates leafy, stem and long vegetables for steady feeding.

• Stainless steel machine body offers durability, corrosion resistance and easier daily cleaning.

Centralized control panel provides straightforward operation and convenient production adjustment.

• Heavy-duty caster wheels make the machine easier to move, position and clean around.

Video of the Equipment in Operation

The operating video demonstrates the continuous feeding process, dual-head vegetable cutting functions and finished cutting results under actual working conditions.

Machine Overview

The JX-801 integrates a conveyor-type cutting section with a rotary cutting section. Leafy and long vegetables are placed on the conveyor and guided toward the cutting area for uniform chopping or cut-to-length processing. Root vegetables and firm produce can be fed through the hopper for slicing, shredding, strip cutting or dicing, depending on the installed cutting disc or cutter assembly.

This dual-head arrangement allows processors to handle different vegetables without purchasing two separate machines, helping save workspace, simplify production and improve equipment utilization.

Suitable Products and Applications

The conveyor cutting section is suitable for cabbage, Chinese cabbage, lettuce, spinach, celery, leeks, scallions, chives, coriander, fennel, garlic sprouts, green beans and other leafy, stem or long vegetables.

With the appropriate cutting disc or cutter assembly, the rotary processing section can handle potatoes, sweet potatoes, carrots, white radish, cucumber, zucchini, onion, ginger, taro, eggplant and selected firm fruits or produce with suitable size and texture. Finished products may include slices, strips, shreds, cubes, short sections and chopped vegetables.

The machine can support vegetable preparation for stir-fried dishes, hot pot ingredients, salads, soup ingredients, dumpling and baozi fillings, pickled vegetables, frozen vegetable products, dehydrated vegetable processing and ready-to-cook meal production.

Typical users include central kitchens, fresh-cut vegetable factories, frozen-food plants, prepared-food manufacturers, catering suppliers, chain restaurants, school and factory cafeterias, supermarket processing centers and agricultural product processing facilities.

Production Applications: Leafy Vegetable Cutting, Root Vegetable Slicing, Potato Strip Cutting, Carrot and Radish Dicing, Salad Preparation and Central Kitchen Processing

Dual-Head Processing for Flexible Vegetable Production

The main advantage of the JX-801 is its ability to process different vegetable categories on one production platform. Operators can use the conveyor side for continuous cutting of leafy and long vegetables while using the rotary section for root vegetable processing.

This flexible configuration helps reduce manual handling and machine changeover requirements when a kitchen or factory produces multiple vegetable products. Uniform cutting also improves cooking consistency, portion control, product appearance and the efficiency of downstream processes such as mixing, seasoning, freezing, drying or packaging.

Technical Specifications

Technical specifications are based on the current product parameter image. Actual output may vary according to the vegetable type, cutting size, cutter configuration and feeding method. Voltage and plug specifications can be customized according to the destination country.

Product Details

1. Large Root Vegetable Feed Inlet

The wide hopper supports convenient feeding of potatoes, carrots, radishes, onions and other firm produce, making the machine suitable for continuous commercial vegetable preparation.

2. Stainless Steel Machine Body

The stainless steel construction provides good corrosion resistance and durability while helping operators maintain a cleaner food-processing environment.

3. Centralized Control Panel

The clearly arranged control panel makes the machine easy to start, stop and adjust during production. Its elevated position also provides convenient access for the operator.

4. Conveyor Feeding System

The conveyor section provides stable feeding for leafy, stem and long vegetables, helping maintain more consistent cutting length and reducing repetitive manual knife work.

5. Multifunctional Cutting Configuration

Different cutting discs and cutter assemblies can be selected according to the required finished product, including slices, strips, shreds, cubes and chopped vegetable sections.

6. Mobile Caster Wheels

The sturdy caster wheels allow the machine to be repositioned for production, cleaning or maintenance while helping commercial kitchens use their available workspace more efficiently.

Why Choose the JX-801 Dual-Head Vegetable Cutter?

• Handles both leafy vegetables and firm root vegetables.

• Produces multiple cutting shapes for different food products.

• Supports continuous production with a capacity of up to 1000 kg/h.

• Helps reduce manual cutting labor and preparation time.

• Improves finished-product consistency and portion control.

• Suitable for multi-product central kitchens and food factories.

• Customizable voltage and cutting configurations are available for different markets.

FAQS

1. What vegetables can the JX-801 process?

The machine can process a wide range of leafy, stem, long and root vegetables, including cabbage, lettuce, celery, leeks, scallions, garlic sprouts, potatoes, carrots, radishes, cucumbers and onions. Suitability depends on the vegetable size, firmness and required cutting result.

2. What cutting shapes can this machine produce?

With the appropriate cutting disc or cutter assembly, the JX-801 can produce slices, strips, shreds, cubes, chopped sections and other common vegetable cuts. Please provide photos and dimensions of your required finished product before ordering so we can recommend the correct configuration.

3. Can the cutting size be adjusted?

Yes. The stated cutting range is 1–60 mm. The available adjustment method and finished size depend on the selected cutting section, cutter configuration and vegetable being processed.

4. Can both cutting heads operate for different vegetables?

The machine integrates a conveyor cutting section and a rotary cutting section for different vegetable categories. This makes it suitable for facilities that regularly process both leafy vegetables and root vegetables. The operating arrangement should follow the supplied machine instructions.

5. What is the actual production capacity?

The reference production capacity is approximately 600–1000 kg/h. Actual output depends on the vegetable type, feeding speed, cutting size, operator experience and cutter configuration.

6. Can the voltage, plug and cutters be customized?

Yes. The voltage and plug can be configured for the destination country. Cutting discs and cutter assemblies can also be selected according to the vegetables and finished cutting shapes required. Please send us your raw-material photos, dimensions and desired cutting results before quotation.
